The Norcom Straight was launched under the mantra: Fit Comes First. It was developed in the A2 Wind Tunnel to be one of the fastest bikes in the world. But more importantly, it was designed to offer more positioning options than any other superbike on the market; Fuji believes that the more adjustability available, the more easily riders are able to dial-in their best, most aerodynamic position, one that doesn't constrict their lungs or compromise their hip flexors and allows them to find their optimal level of comfort, therefore, increasing their efficiency and speed. Add to that ease of maintenance and assembly/disassembly and the Norcom Straight is the obvious choice for your next Tri or TT bike.

C10 Ultra high-modulus carbon frame with RIB technology, a reinforcing rib that runs the length of the oversized downtube and fork blades
Frame pocket engineered into the head tube allows for 135mm of cockpit height adjustability
3D-forged Oval Concepts stem is available in six lengths and two rise options allowing for a total of 24 possible stem positions
Integrated 400mm seat post offers 180mm of adjustable seat height and 70mm in fore/aft movement, which equates to a range of effective seat tube angles from 74
TTV brakes positioned at the rear of the fork on the trailing edge of the airfoil improve aerodynamics, producing 18% less drag than front-mounted designs
Horizontally-adjustable vertical rear dropouts

Size

S (49cm)

Color

Satin Citrus/Cyan

Frame

C10 high-modulus aero carbon tubing, integrated seat clamp, integrated head tube, water bottle mount, aero stays w/ chainstay-mounted brake, vertical dropout w/ wheel-position adjustment

Fork

FC-330 carbon aero monocoque w/ 1 1/8" carbon steerer, integrated airfoil brakes

Crankset

Shimano New Ultegra, 52/36T

Bottom Bracket

Shimano, press fit BB86

Pedals

N/A

Front Derailleur

Shimano New Ultegra Di2, braze-on mount

Rear Derailleur

Shimano New Ultegra Di2, 11-speed

Shifters

Shimano New Ultegra Di2 6871 bar-end TT, 11-speed

Cassette

Shimano New Ultegra, 11-28T, 11-speed

Chain

KMC X11SL, 11-speed

Wheelset

Oval Concepts 985, 700c 16/20H aero carbon rims

Tires

Vittoria Rubino Pro Speed, 700 x 23, 150 tpi, folding

Brakeset

TRP aero TTV

Brake Levers

Shimano New Ultegra TT/Tri Di2 6871

Headset

FSA, 1 1/8" press fit top, integrated bottom bearing

Handlebar

Oval Concepts 950, carbon base bar w/ 950 S-bend carbon extensions

Stem

Oval Concepts 760 Aero, forged 7050 stem body, aero faceplate cover, +/-17 degree

Tape

Oval Concepts 300 bar tape, suede

Saddle

Oval Concepts 734T Tri, Dual Zone with synthetic cover, cromo rail

Seatpost

Oval Concepts, aero carbon, multi-position

Weight

19.64 lbs. / 8.92 kg.

Geometry

	Size	S	M	L	XL	XXL
	Bike Size	49cm	51cm	53cm	55cm	57cm
A	Seat Tube Center To Top	473	482	488	522	539
B	Seat Tube Effective	490	510	530	550	570
C	Top Tube Effective	495	510	527	550	567
D	Head Tube Length	85	90	100	140	164
E	Seat Tube Angle	78°	78°	78°	78°	78°
G	Headtube Angle	72.5	72.5	72.5	72.5	72.5
H	Chainstay Length	395	395	395	395	395
I	Wheelbase	960	975	1006	1020	1039
J	Bottom Bracket Drop	68	68	68	68	68
K	Fork Offset	45	45	45	45	45
L	Trail	58.8	58.8	58.8	58.8	58.8
M	Stack	488	493	503	540	565
N	Reach	391	405	420	435	449
O	Standover	770	778	785	821	843
	Stem	80	80	90	90	110
	Handlebar Width	420	420	420	420	420
	Crank	170	172.5	172.5	175	175
	Wheel Size	700	700	700	700	700
	Seat Post Diameter	N/A	N/A	N/A	N/A	N/A
